Helical Rack Geometry (3D)
The part name for the helical rack geometry in 3D is
helical_rack
.
The following sketch shows all the tooth and rack parameters that can be varied to customize the available geometry.
Figure 2-16:
The sketch of the helical rack geometry in 3D.
Optional Features
The following geometry operations are optional in this part:
•
Fillet at the tooth tip
•
Fillet at the tooth root
