Spur Rack Geometry (3D)
The part name for the spur rack geometry in 3D is
spur_rack
.
The following sketch shows all the tooth and rack parameters that can be varied to customize the available geometry.
Figure 2-15:
The sketch of the spur rack geometry in 3D.
Optional Features
The following geometry operations are optional in this part:
•
Fillet at the tooth tip
•
Fillet at the tooth root
