Bevel Gear Geometry (3D)
The bevel gear geometry is available only in 3D. The part name for this is bevel_gear.
The following sketch shows all the tooth and gear parameters that can be varied to customize the available geometry.
Figure 2-13: The sketch of the bevel gear geometry in 3D.
Optional Features
The following geometry operations are optional in this part:
•
Fillet at the tooth tip
•
Fillet at the tooth root
•
Addition of a shaft
•
Hole at the gear center
•
Material removal from the gear blank
