Spur Gear Geometry (External: 2D)
The part name for the external spur gear geometry in 2D is
spur_gear_2d
.
The following sketch shows all the tooth and gear parameters that can be varied to customize the available geometry.
Figure 2-6:
The sketch of the external spur gear geometry in 2D.
Optional Features
The following geometry operations are optional in this part:
•
Fillet at the tooth tip
•
Fillet at the tooth root
•
Hole at the gear center
