Derived Values
Next, evaluate the current.
1
In the Results toolbar click Global Evaluation
.
2
In the Settings window for Global Evaluation, locate the Expression section.
3
In the table, enter the following settings:
4
Click the Evaluate
button.
The current is now limited to approximately 10 A, which is dictated mostly by the external resistor with a much larger resistance than that of the winding. In the previous step, a current of 1 A was applied. Thus, the magnetic flux density is about 10 times larger in the latest solution.
This can also be seen in the |B| and Coil Direction Plot Group.
.
